THREAD
IDENTIFICATION
|
THREAD
|
PART
No.
|
THREAD
|
THREAD
IDENTIFICATION
|
|
O.D.
(approx) 13mm (1/2") x 19T.P.I.
|
1/4"
B.S.P.T.
|
B3389
|
1/4"
B.S.P.T.
|
O.D.
(approx) 13mm (1/2") x 19T.P.I.
|
|
O.D.
(approx) 16.5mm (.650")x 19T.P.I.
|
3/8"
B.S.P.T.
|
B3390
|
3/8"
B.S.P.T.
|
O.D.
(approx) 16.5mm (.650")x 19T.P.I.
|
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
1/2"
B.S.P.T.
|
B3391
|
1/2"
B.S.P.T.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
O.D.
(approx) 13mm (1/2") x 19T.P.I.
|
1/4"
B.S.P.T.
|
B3392
|
3/8"
B.S.P.T.
|
O.D.
(approx) 16.5mm (.650")x 19T.P.I.
|
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
3/8"
B.S.P.T.
|
B3393
|
1/2"
B.S.P.T.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
1/2"
B.S.P.T.
|
B3394
|
3/4"
B.S.P.T.
|
O.D.
(approx) 26.4mm
(1.035") x
14T.P.I.
|
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
3/8"
B.S.P.T.
(taper)
|
B3395
|
3/8"
B.S.P.P.
(parallel)
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
1/2"
B.S.P.T.
(taper)
|
B3396
|
1/2"
B.S.P.P.
(parallel)
|
O.D.
(approx) 21mm
(.826") x
14T.P.I.
|
| O.D.
(approx) 13.5mm (.526") x 18T.P.I. |
1/4"
NPT
|
|
1/4"
NPT
|
O.D.
(approx) 13.5mm (.526") x 18T.P.I. |
| O.D.
(approx) 16.8mm (.66") x 18T.P.I. |
3/8"
NPT
|
|
3/8"
NPT
|
O.D.
(approx) 16.8mm (.66") x 18T.P.I. |
| O.D.
(approx) 21mm (.826") x 14T.P.I. |
1/2"
NPT
|
|
1/2"
NPT
|
O.D.
(approx) 21mm (.826") x 14T.P.I. |
| O.D.
(approx) 13.5mm (.526") x 18T.P.I. |
1/4"
NPT
|
|
3/8"
NPT
|
O.D.
(approx) 16.8mm (.66") x 18T.P.I. |
| O.D.
(approx) 16.8mm (.66") x 18T.P.I. |
3/8"
NPT
|
|
1/2"
NPT
|
O.D.
(approx) 21mm (.826") x 14T.P.I. |
| O.D.
(approx) 21mm (.826") x 14T.P.I. |
1/2"
NPT
|
|
3/4"
NPT
|
O.D.
(approx) 26.3mm (1.035") x 14T.P.I. |
| O.D. (approx) 16.8mm (.66") x 18T.P.I. |
3/8" NPT |
|
9/16" JIC |
O.D. (approx) 14mm (9/16") x 18T.P.I. |
| O.D.
(approx) 16.8mm (.66") x 18T.P.I. |
3/8"
NPT
|
|
3/4"
'O' Ring
|
O.D.
(approx) 19mm (3/4") x 16T.P.I. |
| O.D.
(approx) 21mm (.826") x 14T.P.I. |
1/2"
NPT
|
|
3/4"
'O' Ring
|
O.D.
(approx) 19mm (3/4") x 16T.P.I. |
| O.D.
(approx) 21mm (.826") x 14T.P.I. |
1/2"
NPT
|
|
9/16"
JIC
|
O.D.
(approx) 14mm (9/16") x 18T.P.I. |
| O.D.
(approx) 21mm (.826") x 14T.P.I. |
1/2"
NPT
|
|
3/4"
JIC
|
O.D.
(approx) 19mm (3/4") x 16T.P.I. |
| O.D.
(approx) 21mm (.826") x 14T.P.I. |
1/2"
NPT
|
|
7/8"
JIC
|
O.D.
(approx) 22mm (7/8") x 14T.P.I. |
|
O.D.
(approx) 16.8mm (.66") x 18T.P.I.
|
3/8"
NPT
|
B3406
|
3/8"
B.S.P.P.
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
|
O.D.
(approx) 16.8mm (.66") x 18T.P.I.
|
3/8"
NPT
|
B3407
|
1/2"
B.S.P.P.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
1/2"
NPT
|
B3408
|
1/2"
B.S.P.P.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
1/2"
NPT
|
B3409
|
3/8"
B.S.P.P.
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
|
O.D. (approx) 26.5mm (1.035") x 14T.P.I.
|
3/4" NPT
|
B94402
|
3/8" NPT
|
O.D. (approx) 16.8mm (.66") x 18T.P.I.
|
|
O.D.
(approx) 26.5mm
(1.035")
x 14T.P.I.
|
3/4"
NPT
|
B3410
|
1/2"
B.S.P.P.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
9/16"
x 18T.P.I.
|
9/16"
J.I.C.
|
B3397
|
3/8"
B.S.P.T.
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
|
3/4"
x 16T.P.I.
|
3/4"
J.I.C.
|
B3398
|
1/2"
B.S.P.T.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
7/8"
x 14T.P.I.
|
7/8"
J.I.C.
|
B3399
|
1/2"
B.S.P.T.
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
9/16"
x 18T.P.I. + O-Ring groove
|
9/16
O-RING
|
B3400
|
3/8"
B.S.P.T.
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I.
|
|
3/4"
x 16T.P.I. + O-Ring groove
|
3/4
" O-RING
|
B3401
|
1/2"
B.S.P.T
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
| 3/4"
x 16T.P.I. + O-Ring groove |
3/4
" O-RING
|
|
3/8"
B.S.P.T.
|
O.D.
(approx) 16.5mm (.650") x 19T.P.I. |
|
7/8"
x 14T.P.I. + O-Ring groove
|
7/8
O-RING
|
B3402
|
1/2"
B.S.P.T
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
|
16mm
x 1.5mm pitch
|
16mm
x 1.5mm
|
B3411
|
1/2"
B.S.P.T
|
O.D.
(approx) 21mm (.826") x 14T.P.I.
|
